Lx 400 Trinocular Polarizing Microscope
From the most basic to the more complex laboratory applications, the Lx 400 stands strong as a truly modular system. With an Infinity corrected Plan Achromatic optical system, users will enjoy crisp images with excellent colour fidelity and high accuracy in image rendition for a wide spectrum of specimens.
Equal attention is given to the quality of this system's mechanical components, producing robust performance throughout the life of your microscope. With the LX series' cost effective synergy of beauty and brains, a balanced microscope no longer has to be a thing reserved for the financially privileged.
Infinity Corrected Plan Achromatic objectives and Extra Wide Field eyepieces provide brilliant images with pristine color fidelity and superb contrast. The system allows for introduction of accessories in optical path without loss of performance. Highly efficient Halogen or energy friendly LED light source options available. Coupled with well designed optics, the system provides brilliant images.
Strain-free operation is provided through an extremely ergonomic design with comfortable hand rests and a conveniently positioned focus drive.
- Stand: Single mold sturdy stand with anti rust materials. Extended base for better stability
- Viewing Bodie: Siedentopf Trinocular head, 30° inclined, 360° rotatable, Inter pupillary distance 48 - 75mm
- Diopter adjustment: +/- 6 dioptres
- Eyepiece: Focusable wide field eyepiece* 10x/20mm with foldable eye guard, anti fungal
- Nosepiece: Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip
- Polarizing attachment: Bertrand lens, Lamda, Quarter Lamda, Quartz Wedge and polarizer with lock
- Objectives: RP series infinity corrected DIN Plan Achromatic objectives* 4x (W.D. 30.0MM), 10x (W.D. 7.00MM), 40x (W.D. 0.65MM), (spring loaded, oil), anti fungal
- Stage: Circular, rotatable to 360°, diameter 160mm vernier graduated scale and spring clips provided
- Condenser: Sub stage Abbe condenser NA 1.25 with aspheric lens*. Iris diaphragm with blue day light filter. Rack and pinion movements on stainless steel guides
- Focusing: Coaxial coarse and fine focusing on ball drive system for smooth operation
Illumination
- Illumination:Halogen 6V20W illumination with variable illumination control. Up to 500 hours of Halogen lamp life
- Electrical: Universal input 100V - 240V AC, 50/60Hz. Built in voltage stabilizer
- Optional accessories: Zernike Phase contrast kit with RP series Phase objectives 10x/20x/40x/100x, Dark field kit, Dual View attachment, Fluorescence attachment; Video adapter
