PixelITPro is a complete solution for capturing, managing and documenting medical images and videos. Designed for surgical and medical microscopes, cameras and DICOM modalities, it combines high-quality image and 4K video capture with patient management, reporting, DICOM/PACS integration and centralized data access.


"Wireless access        to patient data and reports from mobile devices."



Key Specifications

• 4K image and video capture
• Smooth recording with H.264 compression
• Image formats: DICOM, JPEG, BMP
• Video formats: DICOM, MP4, AVI
• Picture-in-Picture (PIP)
• Image annotation, cropping and video trimming
• USB foot pedal and camera control support

• Compatible with a wide range of medical microscopes, endoscopy and camera systems
• HDMI · HD-SDI · SDI · DVI · BNC · RCA · S-Video

• DICOM image and report saving
• DICOM send / receive
• PACS integration
• DICOM Modality Worklist (MWL)
• DICOM video conversion
• Supports DICOM, MPEG-4, H.264 and MPEG-2 video
• Combines DICOM and non-DICOM images in the same report

• Patient and procedure management
• Customizable medical reports
• PDF, DICOM and Word/RTF reports
• RTF report editing
• EMR / HL7 / RIS integration
• Visit comparison
• Statistical data analysis
• Multi-language support

• Stand-alone or client-server operation
• Centralized database across multiple workstations and procedure rooms
• Import, export and archive
• USB, CD/DVD and network export
• Email sharing
• Remote recording and synchronization
• Secure live streaming
• Centralized access to patient data, images, videos and reports

"Wireless access        to patient data and reports from mobile devices."

Key Specifications

• 4K image and video capture
• Smooth recording with H.264 compression
• Image formats: JPEG & BMP
• Video formats: MP4 & AVI
• Picture-in-Picture (PIP)
• Image annotation, cropping and video trimming
• USB foot pedal and camera control support

• Compatible with a wide range of medical microscopes, endoscopy and camera systems
• HDMI · HD-SDI · SDI · DVI · BNC · RCA · S-Video

• Patient and procedure management
• Customizable medical reports
• PDF and Word/RTF reports
• RTF report editing
• Visit comparison
• Statistical data analysis
• Multi-language support

• Stand-alone or client-server operation
• Centralized database across multiple workstations and procedure rooms
• Import, export and archive
• USB, CD/DVD and network export
• Email sharing
• Remote recording and synchronization
• Secure live streaming
• Centralized access to patient data, images, videos and reports

At Labomed, harmony has always been our guiding principle for product design. In order to remain true to this philosophy, we proudly present a new dimension of performance, flexibility and economy of modern practices through the PRIMA lite URL. Each microscope is designed to perform in the most demanding clinical environments. The PRIMA lite URL offers a range of ergonomic configurations and accessories to meet all the needs of the urology practice.

Responding to this call, LABOMED was the first to develop a unique LED-based illumination concept for Urology microscopes. This design leadership has delivered an advanced illumination system that is highly efficient, cool and offers true white LED light with lux values approaching those of Xenon, but with a nominal bulb life of 60.000 hours. With most clinics facing space constraints, a microscope needs to be more compact than ever. By housing the LED light source and electronics within the entire arm, the Prima eliminates the need for bulky illumination housings, resulting in an overall space saving of approximately 20% compared to conventional Halogen and Xenon systems.

The PRIMA lite URL is equipped with an apochromatic optical system that promises the finest images in its class. This is achieved through the proprietary Labomed Maxlite coatings, which provide greater efficiency in transmission and reflection across the entire visible spectrum. Maxlite renders the optics with excellent anti-fungal, anti-fog and scratch-resistant properties.

"Experience ergonomic excellence with the PRIMA lite URL microscope. Its fluid arm system offers tailored tension controls and vertical adjustment without drift. Advanced counterbalancing ensures smooth articulation, enhancing user comfort and efficiency."

MICROSCOPE SPECIFICATIONS

• Labomed PRIMA lite URL microscope with floor mount and CMO 175 mm
• Mounting system: Floor mount with 2 locking wheels
• Observation Tubes: 0-210° inclinable binocular tube
• IPD: 49-78 mm
• Eyepieces: Standard: WF 12.5x/18 mm with eye guards and dioptre lock
• Dioptre adjustment: ± 7
• Magnichanger: Apochromatic 5 step: 0.4x, 0.6x, 1.0x, 1.6x and 2.5x MaxLite coated
• Objective: Standard: f 175 mm focusable
  Optional: F 250 mm, f 300 mm and f 400 mm focusable
  NuVar^TM 7: f 290-360 mm WD: 200-270 mm focusable
  NuVar^TM 10: f 300-400 mm WD: 220-320 mm focusable
• FOV: 10.6-66.2 mm
• Fine Focus: Manual, adjustment by rotating ring
• Light Source: 27 W LED, 100-240 V
• Lux: 100 K
• Maximum Wattage: 60 W
• Built-in Filters: Green and yellow
• Microscope Carriers: 120° carrier with fluent movement
• Optional Accessories: Double beam splitter inclined, rotoplate, extender, double iris, single beam splitter, ProLine range of camera adapters and smart phone adapters

> Labomed PRIMA lite URL microscope floor mount
> Objective CMO 175 mm
> Tools for securing base and pillar
> Sterilizable knob covers
> Nylon dust cover

Een hoogwaardige professionele monitor ontworpen voor omgevingen waar helderheid, comfort en betrouwbaarheid belangrijk zijn. Met scherpe Full HD-beeldkwaliteit, nauwkeurige kleurweergave en een energiezuinig ontwerp is deze monitor gebouwd voor intensief dagelijks gebruik in moderne werkomgevingen.


Consistente en nauwkeurige beeldweergave

De monitor is een high-end professioneel display met fabrieksmatige kleurkalibratie voor nauwkeurige en consistente kleuren. Brede kijkhoeken zorgen ervoor dat het beeld helder en onveranderd blijft, zelfs wanneer het vanuit verschillende posities wordt bekeken.

Verminderde oogvermoeidheid bij langdurig klinisch gebruik

De monitor is ontworpen voor langdurig klinisch gebruik en helpt oogvermoeidheid te verminderen tijdens lange procedures waarbij focus en precisie essentieel zijn. Auto Brightness Control past het scherm automatisch aan de omgevingsverlichting aan en zorgt gedurende de dag voor een comfortabele en stabiele kijkervaring. In combinatie met automatische helderheidsaanpassing wordt blauw licht tot 80% verminderd, wat helpt om oogbelasting tijdens gedetailleerd visueel werk verder te verlagen. Daarnaast kan het display tot zeer lage helderheidsniveaus worden gedimd, waardoor het ook comfortabel te gebruiken is in donkere klinische omgevingen waar visuele precisie cruciaal is.

De monitor FlexScan is TÜV Rheinland-gecertificeerd voor lage blauwlichtemissie en flikkervrije prestaties, wat langdurig kijkcomfort ondersteunt in veeleisende professionele omgevingen.



Comfortabel kijken onder alle omstandigheden

Naast helderheids- en blauwlichtregeling beschikt de monitor over extra functies die comfortabel kijken ondersteunen tijdens langdurig klinisch gebruik.



Flikkervrije technologie zorgt voor een stabiel en consistent beeld zonder zichtbaar schermflikkeren, wat helpt om een comfortabele kijkervaring te behouden tijdens langdurig gebruik.



Het anti-reflecterende schermoppervlak minimaliseert reflecties van omgevingslicht, waardoor het beeld helder en goed zichtbaar blijft onder verschillende lichtomstandigheden en visuele belasting gedurende de dag wordt verminderd.

Ruimtebesparende en flexibele positionering voor gemonteerde opstellingen

De monitor FlexScan heeft een compact ontwerp dat eenvoudig past in klinische opstellingen met beperkte ruimte en boven een microscoop kan worden gemonteerd, waardoor de werkruimte netjes en georganiseerd blijft zonder extra ruimte in te nemen. Dankzij de flexibele monitorarm kan het scherm gekanteld en in meerdere richtingen worden versteld, zodat het eenvoudig optimaal gepositioneerd kan worden voor helder en comfortabel kijken tijdens gebruik. De witte afwerking ondersteunt een strakke, klinische uitstraling die goed past in medische omgevingen.

Slimme energiebesparing en energie-efficiëntie

De monitor FlexScan past de helderheid automatisch aan met behulp van een frontsensorsysteem dat het omgevingslicht meet. Hierdoor blijft het kijkniveau gedurende de dag comfortabel zonder handmatige aanpassing. Daarnaast past het systeem de helderheid aan op basis van de weergegeven content om duidelijke zichtbaarheid te behouden met een lager energieverbruik. Wanneer Eco Mode is geactiveerd, werken beide functies samen om het stroomverbruik tot 60% te verminderen in vergelijking met maximale helderheidsinstellingen.

Eenvoudige aansluiting en gebruik

De monitor FlexScan kan eenvoudig worden aangesloten via DisplayPort™- en HDMI®-poorten en werkt daardoor met verschillende systemen. Daarnaast beschikt hij over vier USB-poorten aan de zijkant, waardoor extra apparaten zoals accessoires of hulpmiddelen eenvoudig kunnen worden aangesloten.

Specificaties

SCHERM

• 23,8" IPS Full HD (1920 × 1080) display
• 100 Hz verversingssnelheid
• 350 cd/m² helderheid
• 1500:1 contrastverhouding
• 178°/178° kijkhoeken
• 16,7 miljoen kleuren
• 5 ms responstijd

CONNECTIVITEIT

• DisplayPort, HDMI
• USB-hub met 4× USB-A-poorten
• 1× USB-upstreampoort

ERGONOMIE

• In hoogte verstelbaar, kantelbaar, draaibaar, pivot
• VESA-montage (100 × 100 mm)

VERMOGEN

• 8 W typisch stroomverbruik
• 0,37 W stand-by

ONTWERP

• Witte afwerking
• Plat schermontwerp

GARANTIE

• 5 jaar fabrieksgarantie op alle componenten, inclusief het LCD-paneel*.

*Gebruikstijd beperkt tot 30.000 uur

AFMETINGEN & GEWICHT

• 537,8 × 317,5 × 57 mm
• Gewicht: 3,5 kg

• Single beam splitter up/down, 4K, flat, C-mount (6122504)
• Camera HDMI & USB, 4K HD, USB foot switch, USB stick (6122534)
• Medical power supply 65W, 12V output (A612099-451)
• Adapter for column monitor arm support  (6128900-805)
• Flexible Monitor Arm, white (A612099-426)
• Camera USB output: USB flash disc (included)
• Camera USB mouse: Wireless mouse (included)
• USB video: Yes, this signal be connected directly to the PC
• Mounting system for MTR: Yes
• Bluetooth: No
• WiFi: No
• HDMI: Yes
• Camera power: Yes, built-in the microscope
• Double USB foot switch: Yes (standard setup for operation of the camera but can also be used for the MTR. For MTR add item 81255165-144)

Camera HDMI & USB, 4K HD (6122534)
Next-generation 4K live-view camera with 30 FPS video. Features a high-sensitivity Sony Exmor CMOS sensor for sharp imaging. Compatible with C-mount microscopy systems. Works as a stand-alone recorder via HDMI or streams to a PC via USB. Auto-switches between modes when connected.

The foot switch offers hands-free control in stand-alone mode, with the left paddle for image capture and the right paddle for video start/stop.

Optimized for modern OBGYN practices, the PRIMA C plus is a powerful yet compact microscope for surgical and diagnostic colposcopy. It delivers bright, clear images through high-quality optics and a strong built-in LED light. Designed with ergonomics and flexibility in mind, the 45° viewing head supports a natural and comfortable posture, helping to reduce strain during longer procedures. The space-saving pole stand allows easy integration into any examination or treatment room.




Extended swivel arm for maximum flexibility

The extended 40 cm (2x 20 cm) swivel arm enhances reach and positioning flexibility. It allows smooth horizontal movement and precise placement of the microscope exactly where it is needed. This extended range makes it easier to adapt to different patient positions and treatment setups, improving workflow efficiency and overall comfort. The stable arm construction ensures steady imaging while allowing effortless adjustments throughout the procedure.





46 cm Column with 10 cm Extendable Heigh

The 46 cm column of the PRIMA C plus long version is designed for users who require a higher working position. It is extendable by 10 cm, providing an objective height range of 1034–1134 mm, which allows professionals to maintain a natural and comfortable posture during seated or standing procedures. The adjustable height ensures flexibility for different clinical setups while maintaining excellent stability and ease of use.

For a lower working position, the PRIMA C plus short column is available with a 36 cm column (Article code 6128905) and an objective height range of 934–1034 mm.

High-Performance LED Illumination

The integrated 27W LED illumination system delivers more than 100.000 Lux at a color temperature of 3700K, providing bright and natural light for detailed examinations. Built directly into the magnichanger, the compact LED design keeps the system efficient, cool and reliable, with a long lifetime of up to 50.000 hours.

The apochromatic 5-step optical system ensures sharp, high-contrast images without color distortion. Advanced MaxLite™ coatings reduce reflections and increase scratch resistance, resulting in evenly illuminated, clear images without light spots or shadows.


Technical Specifications

• Mounting system: Floor stand
• Base: Heavy-duty base with pillar
• Vertical movement: 100 mm
• Horizontal swivel arm: 40 cm (2 × 20 cm)
• Weight: Microscope with carrier (2.8 kg), swivel arm (8 kg) and base with pillar (30 kg)

• Magnichanger: Apochromatic 5-step (0.4x, 0.6x, 1.0x, 1.6x, 2.5x)
• Objective: f-300 mm with manual fine focus
• Objective height range: 1034 –1134 mm

• Binocular tube: 45° viewing tube

• Adjustable (standard configuration)

• WF 10x/18 mm with foldable eye guards
• Optional: WF 12.5x/18 mm

• Range: ±5 mm

• Light source: Intelligent 27 W LED system
• Brightness: Up to 100.000 Lux
• Built-in filters: Green

• Input voltage: 100–240 V, 50/60 Hz
• Current: 1.6 Amp

• ProLine™ series camera adapters
• Compatible with digital SLR, video camera and CCD adapters

• Available separately under article code 6128900-887
• Or included when purchasing the documentation kit for PRIMA C+

PACKAGE CONTENTS

> PRIMA C+ microscope 45º head with short column (46 cm)
> Objective CMO 300 mm
> Tools for securing base and pillar
> Sterilizable knob covers
> Nylon dust cover

Key features:

• Robust construction for long-term stability
• Suitable for solid wall mounting (e.g. stone or concrete)
• Supports smooth horizontal positioning of the microscope
• Keeps the floor and workspace clear
• Compatible with Magna microscope configurations

Key features:

• Robust construction for long-term stability
• Suitable for solid wall mounting (e.g. stone or concrete)
• Supports smooth horizontal positioning of the microscope
• Keeps the floor and workspace clear
• Compatible with PRIMA microscope configurations
• Length of bracket: 19 cm

Mounting options: Horizontal and Vertical



The wall mount is available in both horizontal and vertical versions, giving the flexibility to choose the orientation that best fits the workspace, installation requirements and personal preference for a visually appealing setup. Both options maintain a clear workspace and allow easy adjustment of the microscope for optimal positioning.

Click here to view the vertical version ➚
